165-012F Needle Diamond Bur FG Fine grit

165-012F Needle Diamond Bur FG Fine grit

The 165-012F is a diamond bur made with natural diamond, stainless steel, configured with a needle head, fine grit, 313-FG Short shank, 1.2 mm head diameter. It is designed for cavity preparation and restorative adjustment.

Key Features

• Needle head profile for procedures that require this working shape.
• Fine grit for the corresponding adjustment, finishing or polishing step.
• 313-FG Short shank with 1.6 mm diameter for compatible handpieces.
• 1.2 mm head diameter to match the selected product code.

Specifications

• Product code: 165-012F
• Head shape: Needle
• Head diameter: 1.2 mm
• Grit: fine grit
• Shank type: 313-FG Short
• Shank diameter: 1.6 mm
• ISO code: 806.313.165.514.012
• Size: Head diameter 1.2 mm; cutting length 8 mm; total length 22 mm; shank diameter 1.6 mm

Applications

• Cavity preparation and restorative adjustment.
• Use where a needle working shape matches the clinical or laboratory requirement.
• Compatible with handpieces or holders that accept 313-FG Short instruments.
